The colder months often mean packing away the patio furniture and retreating indoors. But what if you could enjoy your outdoor space all year long? With an outdoor patio heater, you can turn your chilly evenings and brisk winter days into cozy, comfortable moments. Thinking about making your patio or deck a cozy, year-round hangout spot? You've come to the right place!
Step 1: Determine Your Heating Dimensions
Let's get started by measuring your space! Just grab a tape measure and find the length, width, and ceiling height of the area you want to keep warm. These simple measurements are the key to figuring out the perfect heater size and where to place it for maximum coziness.
- Heat Coverage: The area your heater will effectively warm.
- Mounting Height: The distance from the floor to where the heater will be installed.
The chart below will help you find the best heater size and mounting height for your space.
|
Heat Coverage |
Mounting Height |
Heater Options |
|
5' x 5' |
6' - 7' |
C15, W15, SL16 |
|
6' x 6' |
7' - 8' |
C20, W20 |
|
7' x 7' |
7' - 8' |
CD30, SL24, W26, WD30 |
|
8' x 8' |
7' - 9' |
C30, SL30, W30 |
|
8' x 10' |
8' - 10' |
CD40, WD40 |
|
9' x 10' |
8' - 10' |
CD50, WD52 |
|
10' x 10' |
8' - 10' |
C40, SL40, W40 |
|
11' x 11' |
8' - 12' |
CD60, WD60 |
Note: Indoor or well-protected environments may exceed average coverage. Heaters may provide less than average coverage in extremely cold or windy conditions.
View detailed specifications for each series below.
|
C-Series |
CD-Series |
SL-Series |
W-Series |
WD-Series |
|
C15 (1500W, 33") |
CD30 (3000W, 33") |
SL16 (1600W, 29.5") |
W15 (1500W, 33") |
WD30 (3000W, 33") |
|
C20 (2000W, 39") |
CD40 (4000W, 39") |
SL24 (2400W, 42.5") |
W20 (2000W, 39") |
WD40 (4000W, 39") |
|
C30 (3000W, 61.25") |
CD50 (5000W, 39") |
SL30 (3000W, 63.5") |
W26 (2600W, 39") |
WD52 (5200W, 48") |
|
C40 (4000W, 61.25") |
CD60 (6000W, 61.25") |
SL40 (3000W, 63.5") |
W30 (3000W, 61.25") |
WD60 (6000W, 61.25") |
|
W40 (4000W, 61.25") |
Step 2: Choose Your Heater
Now that you know what your space needs, it's time for the fun part: picking out the perfect heater! Infratech has several different styles to choose from, so you can find one that not only works perfectly but also looks great with your home's design.
Heater Series Comparison
|
Series |
Key Features |
Best For |
|
Single element, low profile, streamlined design, low clearance. |
Indoor/outdoor, streamlined look, optimal warmth and style. |
|
|
Dual element, low profile, higher wattage options than C-Series. |
Indoor/outdoor, concentrated heat, larger spaces. |
|
|
Sleek, modern, narrow profile, low clearance, available in multiple finishes. |
Adding designer appeal, pergolas, gazebos, or cabanas where the heater should blend in. |
|
|
Single element, low-profile, low clearance. |
Basic outdoor installations, properties with minimal power allotment. |
|
|
Dual element, high-powered, concentrated heat. |
Recessed applications, large-scale coverage, premium outdoor heating. |
Step 3: Select Your Controls
Choosing the right control system is a fun way to customize your heating experience. It's all about making your space more comfortable, convenient, and energy efficient—so you can relax and enjoy the perfect amount of heat, every time.
Control System Options
|
Control Type |
Features |
Best For |
|
Value Controls |
A simple, ready-made solution for any budget. Available in ON/OFF or Duplex (half/full power) options. |
A simple, no-fuss solution for basic heating needs. |
|
Solid State Custom Controls |
Custom-built to your project specifications. Allows for multiple heating zones and intensity adjustments. |
Projects requiring zoned heating and precise control. |
|
Home Management System Integration |
Integrates heaters into existing smart home systems with a 0-10 volt DC input. |
Seamless control of your heating system through your smart home platform. |
Step 4: Mounting Your Heater
When it comes to installation, you've got options! All Infratech heaters are designed to be super versatile. Whether you prefer a clean, built-in look with a flush mount or a simple wall/ceiling mount, you can place your heater in the perfect spot to both heat your space and complement its style.
Ready to mount your new heater? Here’s a quick guide to your options!
- Wall Mount: This is a great choice for aiming heat outward, into the center of a room or patio. It works with all Infratech heaters and is included with your purchase.
- Ceiling Mount: Perfect for directing warmth straight down over a specific area, like a cozy dining nook or your favorite seating area. This mount also works with all heaters and is included.
- Pole Mount: If your space doesn't have a wall or ceiling—like an open patio or a rooftop—a pole mount is the ideal solution. It's compatible with W & WD series heaters and requires an additional purchase.
- Flush Mount: For a sleek, high-end look, a flush mount allows your heater to be installed directly into the ceiling, creating a seamless finish. This is for W & WD series heaters, and the ceiling must be flat and horizontal. It requires an additional purchase.
Making your outdoor kitchen or patio comfortable and inviting all year long is easier than you think. By following these simple steps, you can confidently choose the perfect Infratech heating system for your home. Now you're ready to create a cozy oasis where you, your family, and your friends can make lasting memories, no matter the season.
For more information on outdoor heaters and to browse our full selection of Infratech heaters and accessories, visit Grillscapes, or give us a call today!
